GPD-180 – High Pressure Pumps

GPD-180 - High Pressure Pumps

Technical Data

Air Drive Dressure pL: 1-10 bar / 14.5 – 145psi
Outlet Pressure at an air drive of 10 bar/145 psi: 1,920 bar/ 27,840 psi
Pressure Ratio: 1:192
Displacement Volume/Double Stroke 69 cm³ / 4.2 cu.inch
Inlet Connections: 1/4″ NPT
Outlet Connections: 6H (3/8″)
Air Drive Connections: 3/4″ NPT
Maximum Operating Tempreature: 60°C
Net Weight: 58 kg
Length: 343 mm
Width: 300 mm
Height: 777 mm

For Complete Product Information Visit or Download PDF. GPD-180 High Pressure Pumps   pdf

DLE180 Flow Chart

gpd-180-flowchart
