Technical Data
Air Drive Dressure pL: | 1-10 bar / 14,5 – 145psi |
Outlet Pressure at an air drive of 10 bar/145 psi: | 3000 bar/ 43,500 psi |
Pressure Ratio: | 1:374 |
Displacement Volume/Double Stroke | 508 cm³ / 31.0 cu.inch |
Inlet Connections: | 1/4″ NPT |
Outlet Connections: | 6H (3/8″) |
Air Drive Connections: | 3/4″ NPT |
Maximum Operating Tempreature: | 60°C |
Net Weight: | 78 kg |
Length: | 343 mm |
Width: | 300 mm |
Height: | 1016 mm |
For Complete Product Information Visit or Download PDF. GPD-180-2 High Pressure Pumps
DLE180-2 Flow Chart
![Maximator-GPD180-2-3](https://i0.wp.com/highpressuretech.com/wp-content/uploads/2019/01/xMaximator-GPD180-2-3.jpg.pagespeed.ic_.4WsVpmokFw.png?fit=800%2C538&ssl=1)
