Technical Data
| Air Drive Dressure pL: | 1-10 bar / 14.5 – 145psi |
| Outlet Pressure at an air drive of 10 bar/145 psi: | 2,580 bar / 37,400 psi |
| Pressure Ratio: | 1:258 |
| Displacement Volume/Double Stroke | 121 cm³ / 7.4 cu.inch |
| Inlet Connections: | 3/4″ NPT |
| Outlet Connections: | 9M (9/16″) |
| Air Drive Connections: | 3/4″ NPT |
| Maximum Operating Tempreature: | 60°C |
| Net Weight: | 78 kg |
| Length: | 343 mm |
| Width: | 300 mm |
| Height: | 1016 mm |
For Complete Product Information Visit or Download PDF. GPD-120 High Pressure Pumps
LE120-2 Flow Chart
