MTHG3-30 Gas Booster System

MTHG3-30 Gas Booster System

MTHG3-30 gas booster systems provide a compact, portable source for increasing gas pressures. These air driven booster systems are shipped assembled and fully tested, ready for turn-key installation. As with standard boosters, gas booster systems also require no electrical power, providing safe and economical operation. Gas booster systems are capable of compressing most gases including nitrogen, argon, helium and hydrogen up to 36,000 psi. Systems featuring special seals and cleaning can pressurize oxygen to 5,000 psi.
Specifications
Stem Type Hazardous Gas
Gas Booster Type DLE30
System Rating 3000 psi
Min. Suction Pressure 175 psi
Dimensions 16″ x 23″ x 28″
Pressure Ratio 30:1
Stall Pressure 30Pa + Ps
Width 16.00 in
Height 23.00 in
Length 28.00 in
Weight 120
